Quality comes with warranty

“DANA” is the most familiar brand and most used brand of drinking water coolers and heat pumps (water heater –cum- chiller indoor and outdoor) .We have exceptional reputation for customer support and model availability with premium features. With More than 40 years of experience in designing equipment exclusively for standard and customized systems, we ensure the highest standards of quality for the global market. Delivery schedules are promptly executed to meet market deadlines and International Standards. Our water coolers are used in Worker Accommodations,Labor Camps,Mosques,Schools,Restaurants.Our products are exported to Qatar,Bahrain,Oman,Kuwait,Saudi Arabia,Kenya,Jordan & vast number of other Arab countries.

KEY FEATURES

1. CONDENSING UNIT

Eco FriendlyHeavy duty, Noiseless, designed for extreme desert conditions. Specially designed for countries with hot climates.Peak cooling capacity is taken at desert ambient 45° c rated conditions to get chilled water at + 12° c to + 5° c.

2. INNER TANK

Eco FriendlyFabricated hygienically with stainless steel 304GR fitted with leak proof hygienic attachments. The inner tank and outer body is insulated under pressure with CFC free polyurethane foam 5o mm thick.

3. DRIP TRAY

Eco FriendlyHigh quality & maintenance free drip proof taps are provided with splash proof grating on the drip tray to get a continuous fresh flow of water.

Choose suitable MODEL:

MODEL:- DANA DWC-20F1
Cooling Capacity 20 US GALS.
Storage Capacity 05 US GALS.
No. of Taps 1
H.P. 1/5
Dimensions 1230(h)X430(w)X430(D)mm
Temperature Range 5° – 12°c
Power Specifications 220-240v 1 PHASE 50HZ

MODEL:- DANA DWC 25-F2
Cooling Capacity 25 US GALS.
Storage Capacity 11 US GALS.
No. of Taps 2
H.P. 1/4
Dimensions 1240(h)X585(w)X605(D)mm
Temperature Range 5° – 12°c
Power Specifications 220-240v 1 PHASE 50HZ


MODEL:- DANA DWC 35-F2
Cooling Capacity 35 US GALS.
Storage Capacity 15 US GALS.
No. of Taps 2
H.P. 1/4
Dimensions 1240(h)X585(w)X605(D)mm
Temperature Range 5° – 12°c
Power Specifications 220-240v 1 PHASE 50HZ

MODEL:- DANA DWC-45F3
Cooling Capacity 45 US GALS.
Storage Capacity 18 US GALS.
No. of Taps 3
H.P. 1/3
Dimensions 1275(h)X585(w)X605(D)mm
Temperature Range 5° – 12°c
Power Specifications 220-240v 1 PHASE 50HZ

MODEL:- DANA DWC-65F3
Cooling Capacity 65 US GALS.
Storage Capacity 20 US GALS.
No. of Taps 3
H.P. 1/3
Dimensions 1275(h)X680(w)X650(D)mm
Temperature Range 5° – 12°c
Power Specifications 220-240v 1 PHASE 50HZ

MODEL:- DANA DWC-85F4
Cooling Capacity 85 US GALS.
Storage Capacity 27 US GALS.
No. of Taps 4
H.P. 1/2
Dimensions 1275(h)X860(w)X650(D)mm
Temperature Range 5° – 12°c
Power Specifications 220-240v 1 PHASE 50HZ


MODEL:- DANA DWC-100F5
Cooling Capacity 100 US GALS.
Storage Capacity 39 US GALS.
No. of Taps 5
H.P. 1/2
Dimensions 1275(h)X970(w)X730(D)mm
Temperature Range 5° – 12°c
Power Specifications 220-240v 1 PHASE 50HZ

MODEL:- DANA DWC-150F4
Cooling Capacity 150 US GALS.
Storage Capacity 50 US GALS.
No. of Taps 4
H.P. 1.5
Dimensions 1330(h)X930(w)X800(D)mm
Temperature Range 5° – 12°c
Power Specifications 220-240v 1 PHASE 50HZ


MODEL:- DANA DWC-250F4
Cooling Capacity 250 US GALS.
Storage Capacity 100 US GALS.
No. of Taps 4
H.P. 2.0
Dimensions 1380(h)X1330(w)X800(D)mm
Temperature Range 5° – 12°c
Power Specifications 220-240v 1 PHASE 50HZ

For Product Catalog, Technical Specifications,

Quality Comes with Warranty

 FOR SALES INQUIRIES :–>Mr Ankur whatsapp-plus+971507983153
Email :- info@danagroups.com / drdana@eim.ae

Download PDF
